Low Temperature RF Cables
Low Temperature Semi-Rigid Coaxial Wire and Low Temperature Tender Ribbon Wire
Low Temperature Semi-Rigid Coaxial Wire
|
Performance Parameters |
CC-086-BeCu |
CC-086-SUS |
SC-086-NbTi |
SC-210-Nb |
|
|
Outer conductor |
Diameter |
0.86±0.025 mm |
0.86±0.025 mm |
0.86±0.025mm |
2.1±0.025 mm |
|
Material |
BeCu |
Stainless steel |
NbTi |
Nb |
|
|
Dielectric layer |
Diameter |
0.66±0.0254 mm |
0.66±0.0254 mm |
0.66±0.025 mm |
0.5±0.025 mm |
|
Material |
PTFE |
PTFE |
NbTi |
PTFE |
|
|
Inner Conductor |
Diameter |
0.20±0.013 mm |
0.20±0.013 mm |
0.20±0.013 mm |
1.62±0.013 mm |
|
Material |
BeCu |
BeCu |
NbTi |
Nb |
|
|
Thermal Conductivity@3K |
1.0E-5 W*cm/K |
7.0E-6 W*cm/K |
/ |
/ |
|
|
Impedance Characteristics |
50±2.5Ω |
50±2.5Ω |
50±2.5Ω |
50±2.5Ω |
|
|
Dielectric Withstanding Voltage |
＞1000 V |
＞1000 V |
＞1000 V |
＞1000 V |
|
|
Transmission Loss |
1.0 GHz |
3.7 dB/m |
4.6 dB/m |
/ |
/ |
|
5.0 GHz |
9 dB/m |
11 dB/m |
/ |
/ |
|
|
10.0 GHz |
13 dB/m |
16 dB/m |
/ |
/ |
|
|
20.0 GHz |
23 dB/m |
28 dB/m |
/ |
/ |
|
|
Working Temperature |
mk~350K |
mk~350K |
mk~4K |
mk~4K |
|
|
Minimum inner bending radius |
3.5 mm |
3.5 mm |
3.5 mm |
3.5 mm |
|
|
Standard length |
1 m |
1 m |
1 m |
1 m |
|
Low Temperature Flexible Ribbon Cable
|
Performance Parameters |
RF Transmission Flexible Ribbon Cabl |
Low Pass Filtering Flexible Ribbon Cable |
|
RF Connections |
SMA |
SMA |
|
Cable Length |
≤100cm |
≤100cm |
|
Operating Frequency |
DC~10GHz |
DC~15GHz |
|
Transmission loss [dB/40cm] |
1GHz -2.76dB |
1GHz ＜-3dB |
|
6GHz -8.02dB |
10GHz ＜-3dB |
|
|
9GHz -10.37dB |
＞20GHz ＜-30dB |
|
|
Heat leakage parameters (40cm, 40K-4.2K) |
0.1mW |
0.1mW |
