LD-100 Series Liquid Nitrogen Variable Temperature Test Dewar

LD-100 Series Liquid Nitrogen Variable Temperature Test Dewar is a liquid nitrogen refrigeration, samples in a vacuum environment, can meet the user's electrical, optical and magnetic experiments such as the needs of the product, the series of products, system stability, easy to operate, cost-effective, is the ideal choice for many scientific research users.

• Temperature range: 77K-350K
• Temperature accuracy: ±100mk
• Sample in vacuum environment
• 10-pin electrical connector for connecting temperature sensors and heater electrical leads
• Optional multi-pin electrical connector for connecting device electrodes to facilitate electrical measurements of the device
• KF25 evacuation connector
• Safety pressure valve
• 1" quartz glass window for viewing samples or performing optical experiments

Liquid Nitrogen Variable Temperature Test Dewar is conveniently filled with liquid nitrogen, variable temperature and temperature control are realized through thermal impedance displacer, built-in heater and temperature controller, with working temperature range of 77K-350K.

Second, the quick release connection is easy to quickly open the sample chamber, can be configured with a variety of electrical leads (such as phosphor bronze cryogenic wire, coaxial cable and tri-coaxial cable, etc.). Two transparent fused silica windows are standard, and other windows can be selected according to the transmission wavelength range to meet the wide spectral range of testing from far/mid infrared, ultraviolet to X-ray. iii.

Typical applications include spectroscopic testing (PL spectroscopy, FTIR and UV-Visible), electrical testing (conductivity, Hall effect) as well as cryogenic imaging, microscopy and component testing.

Lightweight and cost-effective, they are the ideal multi-purpose laboratory thermostats. In addition users can customize it for different testing requirements.

- Customized Dewar for liquid nitrogen testing:
