DC Gauss Meter

The DX-130 is a cutting-edge Hall-effect-based instrument engineered for precise measurement of static and dynamic magnetic fields across a broad spectrum of 0 to ±30,000 Gauss (±3 Tesla). Designed for versatility, it delivers rapid, reliable results in diverse environments, from industrial settings to research labs.

• Measurement Range: ±3T (±30kGs)
• Precision: DC accuracy ±0.5% of reading ±0.05% of range
• Resolution: 0.1mT (1 Gauss)
• Frequency Compatibility: DC fields only
• Analog Output: Three-axis (X/Y/Z) voltage output (±3V F.S.)
• Environmental Tolerance: Operational at 0°C to 50°C; storable at -20°C to 60°C
• Data Interface: RS232/USB via 9-pin D-type port
• Power Supply: 220V AC, 50-60Hz
• Display: 128x64-pixel LCD with 4¾-digit resolution

• Research & Development: Magnetic material analysis, sensor validation
• Defense Systems: Equipment testing, electromagnetic compatibility checks
• Healthcare Technology: MRI ancillary device calibration, biomedical instrumentation
• Industrial QA: Production line monitoring, magnet assembly verification

1. Smart Display: High-contrast LCD with dual unit options (Gauss/Tesla).
2. Data Management: Auto/manual storage modes with recall capability.
3. Adaptive Calibration: Auto-zeroing, range adjustment (manual/automatic).
4. Custom Alerts: Programmable thresholds with audio/visual alarms.
5. Probe Flexibility: Supports multiple sensors (standard 1mm rugged probe included).
6. System Integration: Configurable RS-232C baud rates, optional industrial interfaces.
7. Diagnostic Tools: Real-time temperature monitoring, peak value capture (Max/Min).

• Rugged, portable chassis for fieldwork or lab use
• Intuitive menu navigation with multi-language support
• Low thermal drift: ±(0.03% +1 count)/°C
• Expandable probe ecosystem for specialized measurements

• CE/RoHS-certified components
• Compatible with Windows/Linux data logging software

This instrument empowers engineers and scientists to execute precise magnetic evaluations, enhancing workflow efficiency across critical sectors. Its modular architecture allows seamless adaptation to evolving technical requirements.

(Note: Probe variants and interface modules sold separately. Consult manual for full operational guidelines.)
