Adjustable Magnetic Field Permanent Magnet
Xiamen Dexing Magnet Tech. Co., Ltd. offers cutting-edge Adjustable Magnetic Field Permanent Magnets designed for high-precision applications in scientific research, medical imaging, and industrial systems. Unlike traditional magnets with fixed field intensity, our solutions offer adjustable magnetic field strength and air gap, giving users greater control and flexibility without external power.
In today's increasingly developing field of science and technology, permanent magnets, as the core component of magnetic field generation, are widely used in many fields, such as electronics, medical treatment, scientific research, etc. However, although the constant magnetic field generated by traditional permanent magnets has many advantages, it is often limited in application because of its single structure. To solve this problem, our company has successfully launched the Adjustable Magnetic Field Permanent Magnet - a permanent magnet with adjustable magnetic field strength after in-depth research and technical innovation.
Product Characteristics
Adjustable air gap: This product uses advanced magnetic field control technology so that the size of the air gap around the permanent magnet can be flexibly adjusted according to actual needs. This feature not only ensures the uniformity of the magnetic field distribution but also adapts to the requirements of different installation spaces and improves its convenience.
Adjustable magnetic field strength: The product's built-in magnetic field control mechanism allows continuous adjustment of magnetic field strength. Users can select the appropriate magnetic field strength according to the specific application scenario to meet different requirements.
Uniform and stable area: This product's design fully considers the uniformity of the magnetic field distribution and ensures a uniform and stable magnetic field in the area of action by optimizing the magnetic field distribution structure. This feature makes this product more valuable in scientific research, medical treatment, and other fields.
Function close to the electromagnet: This product's magnetic field control technology makes its function closer to the electromagnet, but compared with the electromagnet, this product can generate a stable magnetic field without an external power supply, reducing energy consumption and maintenance costs.
Application Fields
Scientific research: In physics, materials science, and other scientific research, this product can provide a stable magnetic field environment for various magnetic field-related experiments and promote the in-depth development of scientific research work.
Medical field: In MRI (magnetic resonance imaging) and other medical equipment, this product can be used as a core magnetic field generation element to provide clear and accurate image support for medical diagnosis.
Industrial field: In motors, sensors, and other industrial products, this product can replace the traditional electromagnet to achieve no-power-driven magnetic field control and improve the performance and reliability of the product.
Fourth, product advantages
Innovative technology: Advanced magnetic field control technology is used to continuously adjust the air gap and magnetic field strength to meet the needs of various application scenarios.
High efficiency and energy saving: Stable magnetic fields can be generated without an external power supply, reducing energy consumption and maintenance costs. Widely used: It is suitable for scientific research, medical treatment, industry, and other fields and has broad market prospects.
Stable and reliable: Through optimized design and strict quality control, to ensure that the product has a stable and reliable performance during use.
Technical case
|
Model |
Main technical parameters |
|
DXT100-08 Adjustable air gap permanent magnet |
The magnetic field air gap is adjustable, and the magnetic field is weakened when the distance between the two poles is increased.
The pole diameter and pole surface diameter are 100mm, the air gap is adjustable from 10 to 100mm, and the magnetic field is adjustable from 0.2 to 0.8T. |
|
DXT40-0059 Low magnetic field adjustable permanent magnet |
The magnetic field air gap is fixed, the relative position of the poles is unchanged, and the magnetic field is changed in such a manner as to change the width of the magnetic circuit channel.
Dimensions: 140*65*180mm, pole surface diameter Φ40mm, air gap 15mm, weight: 5Kg
The central magnetic field is continuously adjustable from 16 to 590 Gs, and the adjustment accuracy is 1 Gs.
Center 10*10*10mm spatial uniformity 590Gs=1.6% 16Gs=6% |
|
DXT150-12 Adjustable air gap permanent magnet |
The magnetic field air gap is adjustable, and the magnetic field is weakened when the distance between the two poles is increased. The magnetic field is changed in such a manner as to change the air gap. The structure and operation are simple.
The pole diameter is 150mm, the pole surface diameter is 100mm, the air gap is adjustable from 10 to 100mm, and the magnetic field is adjustable from 0.28 to 1.2T. |
|
DXS-1.2 Double magnetic axis adjustable permanent magnet |
The DXS-1.2 type permanent magnet adjusts the magnetic field by changing the magnetic circuit without changing the relative position of the magnetic pole, thereby realizing the function of the electromagnet without the need for the excitation power source. It is light in weight, easy to operate, and can be manually operated to adjust the magnetic field; the input shaft can be reserved, or it can be connected with a reducer or a stepping motor to adjust the magnetic field strength electrically, and the adjustment precision can reach 1Gs.
Dimensions: 200*150*200MM, weight: 13Kg
Double magnetic axis permanent magnet, magnetic field direction horizontal, pole surface diameter Φ8mm, air gap adjustable range 5mm-25mm. When the air gap is 5mm, the maximum magnetic field is 1.2T, which can be adjusted from 0 to 1.1 T. |
|
DXS50-1 Double magnetic axis adjustable permanent magnet |
DXS50-1 permanent magnet, magnetic surface diameter 50mm, air gap adjustable range 5-100mm, adjustable magnetic field, no change of working air gap when adjusting magnetic field, minimum adjustment fineness of magnetic field is less than 1Gs, continuous adjustment of the magnetic field, zero-crossing ;
When the working air gap is 5mm, the magnetic field range is 0~ plus or minus 1.0T; when the air gap is 10mm, the magnetic field range is 0~ plus or minus 0.5T; when the air gap is 25mm, the magnetic field range is 0~±0.2T. |
Deliver, shipping and serving
In the current business environment, providing excellent logistics services has become the key to earning and maintaining customers' long-term trust. To this end, we always adhere to the "customer-centric" principle, carefully considering sea, air, land, and other modes of transportation, tailor-made for customers to create the most suitable transportation solutions to meet their diverse needs. We are committed to providing excellent service to our customers, ensuring that every shipment is delivered to its destination on time, safely, and accurately. We know that we can remain invincible only by continuously exceeding our customers' expectations in a highly competitive industry. Therefore, we will continue to focus on improving the quality of our services to ensure that our customers can enjoy the highest quality logistics services.
FAQ
Question 1：Adjustable Magnetic Field Permanent Magnet How is the adjustable magnetic field permanent magnet?
Answer: Adjustable Magnetic Field Permanent Magnet adjustment is usually achieved in several ways. A common approach is to "magnetize" or "demagnetize" a permanent magnet using an electromagnetic field, thereby changing its overall magnetic field strength. Another method is to influence the distribution and strength of the magnetic field by mechanically adjusting the internal structure of the magnet, such as changing the distance or Angle between the magnetic poles. In addition, there are some advanced permanent magnet materials whose magnetic field strength can be adjusted by external factors such as temperature, pressure, or light.
Question 2：Adjustable Magnetic Field Permanent Magnet: Is heat generated when adjusting the magnetic field?
Answer: Some heat may be generated when adjusting the Magnetic Field of the Adjustable Magnetic Field Permanent Magnet. This is mainly because changes in the magnetic field may cause changes in the magnetic domain structure inside the magnet, producing energy conversion and release, which is expressed in the form of heat energy. However, this heat generation is usually tiny and can be controlled with proper heat dissipation design to ensure the magnet operates within its normal operating temperature range.
Question 3：Adjustable Magnetic Field Permanent Magnet: Is it affected by external magnetic fields?
Answer: Yes, Adjustable Magnetic Field Permanent Magnet can be affected by external magnetic fields. The external magnetic field may interfere with the internal magnetic field distribution and strength of the magnet, thus affecting its performance. Therefore, when using and adjusting magnets, exposing them to strong external magnetic fields should be avoided. Suppose a magnet needs to be used in an environment where an external magnetic field is present. In that case, appropriate shielding or isolation measures should be taken to reduce the impact of the external magnetic field on the magnet.
